Audio-technica - AT-LP5 Direct Drive Turntable
The AT-LP5 direct-drive turntable brings advanced technology and sleek, contemporary styling together for performance that looks as good as it sounds. Born of Audio-Technica’s rich analog heritage, the AT-LP5 incorporates a J-shaped tone arm that takes its inspiration from the classic A-T models of the 1960s and ’70s. The tone arm features a metallic gimbal suspension system and precision bearings to mitigate tracking errors, and includes an adjustable counterweight and anti-skate control. It comes outfitted with a lightweight (10 g) AT-HS10 headshell and high-performance AT95EX Dual Moving Magnet stereo cartridge, created specifically for this turntable.
Constructed of anti-vibration damping materials with heavy-mass metal chassis inserts, the AT-LP5 turntable is a class leader in limiting low-frequency acoustical feedback. Its precision-machined, die-cast aluminum platter is powered by a direct-drive, high-torque motor, ensuring stable, on-axis rotation at 33-1/3 or 45 RPM. The platter is topped by a 5 mm thick rubber damping mat that improves low-frequency reproduction.
The AT-LP5 features a built-in switchable phono/line preamp that enables it to be connected directly to a computer, home stereo, powered speakers and other components that have no dedicated turntable input. The turntable is also equipped with a USB output for direct connection to a computer, and comes with PC- and Mac-compatible Audacity® software that lets you convert your records to MP3, WAV or other digital audio file formats.
|Type||2-speed, fully manual operation|
|Drive Method Direct Drive||Direct drive|
|Speeds||33-1/3 RPM, 45 RPM|
|Turntable Platter||Die-cast aluminum|
|Starting Torque||>1.6 kgf.cm|
|Braking System||Electronic brake|
|Wow and Flutter||<0.2% WRMS (33 RPM)|
|Signal-to-Noise Ratio||>50 dB|
|Output Level||Pre-amp “PHONO”: 3.5 mV nominal at 1 kHz, 5 cm/sec |
Pre-amp “LINE”150 mV nominal at 1 kHz, 5 cm/sec
|Phono Pre-Amp Gain||36 dB nominal, RIAA equalized|
|USB Function||A/D, D/A - 16 bit 44.1 kHz or 48 kHz USB selectable; |
Computer interface - USB 2.0 compliant Windows XP, Vista or MAC OS X
|Power Supply Requirements||120V AC, 60 Hz|
|Power Consumption||11 W|
|Dimensions||450.0 mm (17.72") W x 352.0 mm (13.86") D x 157.0 mm (6.1") H|
|Weight||10.5 kg (23.1 lbs.)|
|Accessories Included||AT95EX Dual Moving Magnet stereo cartridge with replaceable stylus; AT-HS10 lightweight headshell; power cord; dual RCA (male) to dual RCA (male) stereo cable; 45 RPM adapter; USB cable; recording software; cartridge alignment and overhang adjustment template; dust cover with mounting hardware|
